Examples¶

Explore example diagrams and configurations to learn how to use PinViz.

Quick Start with Built-in Examples¶

The fastest way to try PinViz is using the built-in examples:

# List all available examples
pinviz list

# Generate a specific example
pinviz example bh1750 -o bh1750.svg
pinviz example ir_led -o ir_led.svg
pinviz example i2c_spi -o i2c_spi.svg

All example configurations are available in the examples/ directory.

Example Gallery¶

BH1750 Light Sensor¶

Simple I2C sensor connection demonstrating automatic color coding for I2C bus (SDA/SCL).

Configuration: examples/bh1750.yaml

title: "BH1750 Light Sensor Wiring"
board: "raspberry_pi_5"

devices:
  - type: "bh1750"
    name: "BH1750"

connections:
  - board_pin: 1    # 3V3
    device: "BH1750"
    device_pin: "VCC"

  - board_pin: 6    # GND
    device: "BH1750"
    device_pin: "GND"

  - board_pin: 5    # GPIO3 (I2C SCL)
    device: "BH1750"
    device_pin: "SCL"

  - board_pin: 3    # GPIO2 (I2C SDA)
    device: "BH1750"
    device_pin: "SDA"

show_legend: true

Generate:

pinviz example bh1750 -o bh1750.svg

Result:

BH1750 Light Sensor

LED with Resistor¶

Simple LED circuit demonstrating inline components (resistor on wire).

Configuration: examples/led_with_resistor.yaml

title: "LED with Current-Limiting Resistor"
board: "raspberry_pi_5"

devices:
  - type: "led"
    color: "Red"
    name: "Red LED"

connections:
  # LED Anode to GPIO17 via 220Ω resistor
  - board_pin: 11  # GPIO17
    device: "Red LED"
    device_pin: "+"
    color: "#FF0000"  # Red wire
    components:
      - type: "resistor"
        value: "220Ω"

  # LED Cathode to Ground
  - board_pin: 9  # GND
    device: "Red LED"
    device_pin: "-"
    color: "#000000"  # Black wire

show_legend: true

Generate:

pinviz render examples/led_with_resistor.yaml -o led.svg

Result:

LED with Resistor

Key Features: - Inline resistor component on wire - Custom wire colors (red for power, black for ground) - Simple single-device connection

Traffic Light¶

Multiple LEDs with individual resistors demonstrating parallel device connections.

Configuration: examples/traffic_light.yaml

title: "Traffic Light - 3 LEDs with Resistors"
board: "raspberry_pi_5"

devices:
  - type: "led"
    color: "Red"
    name: "Red LED"
  - type: "led"
    color: "Yellow"
    name: "Yellow LED"
  - type: "led"
    color: "Green"
    name: "Green LED"

connections:
  # Red LED (GPIO17)
  - board_pin: 11
    device: "Red LED"
    device_pin: "+"
    color: "#FF0000"
    components:
      - type: "resistor"
        value: "220Ω"
  - board_pin: 9
    device: "Red LED"
    device_pin: "-"
    color: "#000000"

  # Yellow LED (GPIO27)
  - board_pin: 13
    device: "Yellow LED"
    device_pin: "+"
    color: "#FFFF00"
    components:
      - type: "resistor"
        value: "220Ω"
  - board_pin: 14
    device: "Yellow LED"
    device_pin: "-"
    color: "#000000"

  # Green LED (GPIO22)
  - board_pin: 15
    device: "Green LED"
    device_pin: "+"
    color: "#00FF00"
    components:
      - type: "resistor"
        value: "220Ω"
  - board_pin: 20
    device: "Green LED"
    device_pin: "-"
    color: "#000000"

show_legend: true

Generate:

pinviz render examples/traffic_light.yaml -o traffic_light.svg

Result:

Traffic Light

Key Features: - Multiple devices of the same type - Each LED has its own resistor - Color-coded wires matching LED colors - Multiple ground connections

Multi-Device Setup¶

BH1750 light sensor and IR LED ring demonstrating I2C bus sharing and custom wire colors.

Configuration: examples/bh1750_ir_led.yaml

title: "BH1750 Light Sensor + IR LED Ring"
board: "raspberry_pi_5"

devices:
  - type: "bh1750"
    name: "BH1750 Light Sensor"
  - type: "ir_led_ring"
    name: "IR LED Ring"

connections:
  # BH1750 Light Sensor
  - board_pin: 1
    device: "BH1750 Light Sensor"
    device_pin: "VCC"
    color: "#FF9800"  # Orange
  - board_pin: 9
    device: "BH1750 Light Sensor"
    device_pin: "GND"
    color: "#FFEB3B"  # Yellow
  - board_pin: 3
    device: "BH1750 Light Sensor"
    device_pin: "SDA"
    color: "#4CAF50"  # Green
  - board_pin: 5
    device: "BH1750 Light Sensor"
    device_pin: "SCL"
    color: "#2196F3"  # Blue

  # IR LED Ring
  - board_pin: 2
    device: "IR LED Ring"
    device_pin: "VCC"
    color: "#F44336"  # Red
  - board_pin: 6
    device: "IR LED Ring"
    device_pin: "GND"
    color: "#000000"  # Black
  - board_pin: 11
    device: "IR LED Ring"
    device_pin: "CTRL"
    color: "#F44336"  # Red

show_legend: true

Generate:

pinviz render examples/bh1750_ir_led.yaml -o multi_device.svg

Result:

BH1750 + IR LED Ring

Key Features: - Two different device types - I2C sensor + GPIO-controlled device - Custom color palette for wire differentiation - Multiple power and ground connections

Raspberry Pi Zero 2 W¶

Same BH1750 sensor on the compact Pi Zero board layout.

Configuration: examples/pi_zero_bh1750.yaml

title: "BH1750 Light Sensor - Pi Zero 2 W"
board: "raspberry_pi_zero_2w"

devices:
  - type: "bh1750"
    name: "BH1750"

connections:
  - board_pin: 1
    device: "BH1750"
    device_pin: "VCC"
  - board_pin: 6
    device: "BH1750"
    device_pin: "GND"
  - board_pin: 5
    device: "BH1750"
    device_pin: "SCL"
  - board_pin: 3
    device: "BH1750"
    device_pin: "SDA"

show_legend: true

Generate:

pinviz render examples/pi_zero_bh1750.yaml --no-gpio -o pi_zero.svg

Result:

Pi Zero BH1750

Key Features: - Compact Raspberry Pi Zero 2 W board - Same 40-pin GPIO header pinout as Pi 5 - Smaller form factor visualization - Identical connections work across boards

GPIO Reference Comparison¶

You can control whether to show the GPIO pin reference diagram. Here's a side-by-side comparison:

With GPIO Details¶

Shows complete GPIO pinout reference (~130KB SVG):

pinviz example bh1750 --gpio -o diagram.svg

BH1750 with GPIO

Without GPIO Details¶

Cleaner, more compact diagram (~85KB SVG, 35% smaller):

pinviz example bh1750 --no-gpio -o diagram.svg

BH1750 without GPIO

When to use each: - With GPIO (--gpio): Initial learning, documentation, when you need the pinout reference - Without GPIO (--no-gpio): Cleaner diagrams, presentations, when space is limited

More Examples¶

All example files (YAML and Python) are available in the repository:

YAML Examples: examples/ directory
Python Examples: Same directory with _python.py suffix
Generated Diagrams: images/ directory

Available Examples¶

bh1750.yaml / bh1750_python.py - I2C light sensor
led_with_resistor.yaml / led_with_resistor_python.py - LED with inline resistor
traffic_light.yaml - Three LEDs with resistors
bh1750_ir_led.yaml / bh1750_ir_led_python.py - Multi-device setup
ir_led_ring.yaml / ir_led_ring_python.py - IR LED ring module
multi_device.yaml / multi_device_python.py - Multiple I2C devices
ds18b20_temp.yaml / ds18b20_temp_python.py - 1-Wire temperature sensor
pi_zero_bh1750.yaml - Pi Zero board example

Contributing Examples¶

Have a cool diagram to share? We'd love to include it!

Submission guidelines:

YAML Configuration: Well-commented configuration file
Python Version (optional): Equivalent Python code
Description: Brief description of what the example demonstrates
Generated SVG: The rendered diagram
Real-world use case: Bonus points for practical applications!

Submit your example as a pull request to the examples/ directory.

What makes a good example: - Clear, well-commented configuration - Demonstrates a specific feature or pattern - Real-world use case or common scenario - Clean, readable diagram output - Helpful for learning
